3D Tube Laser Cutting Machine ETL-YG2000

  • Brand：   ETL
  • Model：   ETL-YG2000
    • The ETL-YG2000 is a high-performance 3D laser cutting system specifically engineered for industrial-grade tube and pipe processing. Integrating precision mechanics, advanced CNC technology, and high-power fiber lasers, this machine supports fully automated high-speed cutting, holing, and cutoff for round, square, rectangular, and various special-shaped profiles. Equipped with a high-precision 3D cutting head, it masters complex intersecting lines and beveling tasks, serving as the ultimate intelligent solution for the metal tube processing industry. Widely used in industries such as fitness equipment, office furniture, medical devices, automotive components, power facilities, kitchen and bathroom hardware, and architectural steel structures.

    hdjg@etl-laser.com

    • Description
    • Viedos

      3D Tube Laser Cutting Machine ETL-YG2000

          The ETL-YG2000 is a professional-grade 3D fiber laser tube cutting machine engineered for complex metal fabrication. Featuring advanced multi-axis CNC control and a high-precision 3D cutting head, it masters beveling, intersecting line cutting, and 3D spatial contours with micron-level accuracy. Designed for global industrial standards, the ETL-YG2000 offers an automated, high-speed solution for round, square, and irregular profiles, significantly reducing production cycles for modern smart factories.

      Applicable Materials & Industries

      Materials:

      • Carbon Steel & Mild Steel: Up to 15-20mm (depending on power).

      • Stainless Steel: High-quality burr-free cutting for 304/316 grades.

      • Aluminum Alloys: Excellent performance on reflective materials.

      • Specialty Metals: Brass, Copper, Galvanized pipes, and Titanium.

      • Profiles: Round, square, rectangular, oval, H-beam, U-steel, and L-angle steel.

      Industries:

      • Automotive & Transportation: Exhaust systems, chassis frames, and structural components.

      • Heavy Construction: Steel structures, bridges, and architectural frameworks.

      • Fitness & Medical: Specialized gym equipment frames and high-precision medical furniture.

      • Furniture & Decoration: Metal desks, shelving, and intricate interior designs.

      • Energy & Power: Solar tracking brackets and power transmission towers.

      Core Specifications of ETL-YG2000:

      Feature Specifications (ETL-YG2000)
      Laser Power 2000W - 6000W (Fiber Laser Source)
      3D Cutting Capability Bevel cutting up to ±45°
      Tube Processing Range Φ20mm - Φ220mm (Round) / 20x20mm - 150x150mm (Square)
      Max Tube Length 6000mm / 9000mm / 12000mm (Customizable)
      Positioning Accuracy ±0.03mm/m
      Repeated Positioning ±0.02mm
      Max Rotation Speed 120 - 150 RPM
      Chuck System Intelligent Pneumatic Dual/Triple Chucks (Zero Tailing)
      Automation Full-automatic Bundle Loading System (Optional)
      ETL-YG2000 3D Tube Laser Cutting Machine, an industrial fiber laser system designed for high-precision processing of round, square, and special-shaped metal pipes.Close-up shot of the ETL-YG2000 3D cutting head performing complex intersecting line cutting on a stainless steel tube.The ETL-YG2000 fully automated tube feeding system, showcasing its capability for continuous, unattended production with raw metal tube bundles.Detail view of the ETL-YG2000’s intelligent dual pneumatic chucks, designed for stable clamping and damage protection of large-diameter tubes during rotation.A wide shot of the ETL-YG2000 3D tube laser cutting machine’s heavy-duty bed and safe enclosure, illustrating a modern, high-power industrial laser installation.

      3D Tube Laser Cutting Machine - FAQ

      Q1: What is the main difference between a 3D tube laser and a standard 2D laser?

      Answer:

      Ever Tech Laser provides the following comparison to help you choose the right technology for your production line:

      Feature Standard 2D Tube Laser ETL-YG2000 3D Tube Laser
      Cutting Head Fixed vertical (90°) Multi-axis swinging (±45°)
      Beveling Not possible High-precision bevel cuts
      Complex Intersections Basic holes and cut-offs Advanced spatial curves & interlocking joints
      Secondary Processing Requires manual grinding for welding Ready-to-weld finishes (No secondary work)

      Q2: What materials and tube shapes can the ETL-YG2000 process?

      Answer:

      • Supported Shapes: Round, Square, Rectangular, Oval, H-Beam, U-Steel, and Angle Steel.

      • Material Thickness:

        • Carbon Steel: 1mm – 20mm

        • Stainless Steel: 1mm – 12mm

        • Aluminum/Brass: 1mm – 8mm

      • Tube Diameters: Round tubes up to Φ220mm; Square tubes up to 150mm x 150mm.

      Q3:What are the specific capabilities of the 3D Bevel Cutting feature?

      Answer:

      The core strength of the Ever Tech Laser 3D system lies in its precision oscillating head:

      • Swing Angle: Up to ±45° for perfect V, Y, or K-shaped grooves.

      • Accuracy: Positioning accuracy of ±0.03mm and repeatability of ±0.02mm.

      • Advantage: This allows for seamless pipe-to-pipe fitment, which is critical for high-strength welding in construction and automotive frames.

      Q4: What is the price of the ETL-YG2000 and the estimated ROI?

      Answer:

      The investment for an ETL-YG2000 varies based on the chosen fiber laser source (2kW to 6kW) and automation level.

      • Price Range: Please contact our sales team for a customized quote based on your local currency and shipping requirements.

      • ROI Analysis: Most Ever Tech Laser clients achieve a full Return on Investment within 12–18 months due to a 50% reduction in labor costs and a 30% increase in material utilization through intelligent nesting software.

      Q5:Does the machine include an automatic loading and unloading system?

      Answer:

      Yes, efficiency is a priority at Ever Tech Laser.

      • Full Automation: The ETL-YG2000 can be equipped with an Automatic Bundle Loader that measures, aligns, and feeds tubes into the machine without manual intervention.

      • Uninterrupted Production: This system allows for "lights-out" manufacturing, where the machine continues to process entire bundles of raw pipe automatically, significantly boosting your daily output.

      Q6: Which software is used, and is it compatible with my CAD files?

      Answer:

      The ETL-YG2000 uses a professional 3D bus-system control software optimized for complex tube processing.

      • File Compatibility: Seamlessly imports STEP, IGS, DXF, and SAT files from SolidWorks, AutoCAD, and Inventor.

      • Smart Features: Includes Auto-Nesting to minimize tailing waste and Real-time Collision Avoidance to protect the cutting head during complex 3D maneuvers.
